Ajax EN54 FireProtect (heat/sounder) black

Skip to the end of the images gallery

Skip to the beginning of the images gallery

€122.52 €152

Pre-order

SKU

119916.274.BL1

Product files

Datasheet

Product details

Product parameters
Length	124
Width	124
Height	48

Toote kirjeldus

Ajax EN54 FireProtect (Heat/Sounder) Jeweller combines a heat detector with a sounder. It responds to a rise in temperature and sounds the alarm itself, so the warning is heard exactly in the room where the fire started.

A heat detector suits places where a smoke detector would cause false alarms: kitchens, boiler rooms, car parks, workshops and dusty production areas. The device belongs to the EN 54 compliant Ajax Fire range controlled by the EN54 Fire Hub, and the sound of all devices connected to the same control and indicating equipment is synchronised automatically.

A three-colour LED shows the state of the detector — alarm, test or fault. The SmartBracket mounting panel with a lock holds it on the ceiling and the tamper button reports removal. The pre-installed CR123A batteries last for years, replacement needs no tools, and reverse polarity protection prevents damage.

Features

Heat detector and sounder in one — the alarm sounds in the right room
Suited to kitchens, boiler rooms, car parks and dusty areas
Sounders are synchronised automatically
EN 54 compliant, part of the Ajax Fire system
Three-colour LED indication: alarm, test, fault
SmartBracket mount with a lock and a tamper button
Pre-installed CR123A batteries, tool-free replacement
Jeweller radio up to 1,700 m, encrypted and frequency-hopping

Technical data

Communication protocol	Jeweller
Radio communication range	up to 1.700 m
Radio communication encryption	Yes
Power supply	2 × CR123A
Battery life	up to 5 years
Protection against spoofing	Yes
Ingress protection rating	IP21C
Operating temperature range	from 0 °C up to +50 °C
Operating humidity	up to 80%
Dimensions (L × W × H)	124 × 124 × 48 mm
Weight	278 g
Warranty	24 months
