Ajax EN54 FireProtect (smoke/sounder) black

€131.94 €164
Pre-order
SKU
119920.276.BL1
Product files
Product details
Product parameters
Length 124
Width 124
Height 48
Toote kirjeldus

Ajax EN54 FireProtect (Smoke/Sounder) Jeweller combines a smoke detector with a sounder: the detector that finds the fire sounds the alarm itself, without waiting for a command from the control panel. The alarm is therefore heard exactly in the room where the smoke appeared.

Smoke is detected by a dual-spectrum optical sensor that judges the size of particles in the air and tells smoke from water vapour, so no false alarms occur near a bathroom or a kitchen. A patented smoke chamber protects the sensor from dust, dirt and insects.

The device belongs to the EN 54 compliant Ajax Fire range controlled by the EN54 Fire Hub, and the sound of all devices connected to the same control and indicating equipment is synchronised automatically. A three-colour LED shows the state, the SmartBracket mount with a lock holds the detector on the ceiling, and the tamper button reports removal. The pre-installed batteries last for years and can be replaced without tools.

Features

  • Smoke detector and sounder in one — the alarm sounds in the right room
  • Dual-spectrum optical sensor that tells smoke from water vapour
  • Patented smoke chamber protects against dust and insects
  • Sounders are synchronised automatically
  • EN 54 compliant, part of the Ajax Fire system
  • Three-colour LED indication: alarm, test, fault
  • SmartBracket mount with a lock and a tamper button
  • Pre-installed CR123A batteries, tool-free replacement

Technical data

Sensing elementdual-spectrum optical sensor / Detects smoke based on the size of particles in the air.
Communication protocolJeweller
Radio frequency band866.0–866.5 MHz / 868.0–868.6 MHz / 868.7–869.2 MHz / 905.0–926.5 MHz / 915.85–926.5 MHz / 921.0–922.0 MHz / Depends on the sales region.
Radio communication rangeup to 1.700 m
Radio communication encryptionYes
Power supply2 × CR123A
Battery lifeup to 5 years
Protection against spoofingYes
Ingress protection ratingIP21C
Operating temperature rangefrom 0 °C up to +50 °C
Operating humidityup to 80%
Dimensions (L × W × H)124 × 124 × 48 mm
Weight295 g
Warranty24 months
