AMC Soutdoor outdoor detector | white | dual digital PIR | 6–12 m | IP65

Soutdoor/L is a dual digital PIR outdoor detector whose analysis takes into account the two most important features of a movement – speed and intensity. By comparing them, the detector tells repetitive movements from intrusion and lowers false alarms. Fully digital temperature compensation keeps performance high with large thermal variations. Coverage is up to 12 m at 90°; with interchangeable lenses the detector suits different mounting heights and curtain protection.

Key features

• 2 digital PIR sensors, AND function (4 s)
• Range 6…12 m, 90°
• Double pulse function
• Interchangeable Fresnel lenses
• Solid-state relays: alarm and tamper (NO/NC)
• Pet immunity
• IP65, −30…+70 °C
