Hanwha XRN-6420DB4 network video recorder (NVR), 64 channels, 16x HDD

Skip to the end of the images gallery

Skip to the beginning of the images gallery

€14,140.00 €17,534

Pre-order

SKU

XRN-6420DB4

Product files

Datasheet

Product details

Product parameters
Manufacturer	Hanwha Vision
Length	440
Width	132
Height	571

Toote kirjeldus

Hanwha XRN-6420DB4 is a 64-channel network video recorder (NVR) for IP cameras with 16 HDD bays. A network video recorder receives the IP cameras' video streams, records them on hard disks and lets you watch live and recorded video on a local monitor, a computer or a smartphone.

Key features

64 IP camera channels, cameras up to 32 MP
Recording bandwidth up to 520 Mbps
16 SATA HDD bays, up to 160TB in total
RAID: RAID-5/6(Array Size : 8 HDDs x 2 Array)
Monitor output: [Dual Display] HDMI 1: 3840 x 2160 (30Hz) HDMI 2: 1920x1080 (60Hz)
Recording H.265, H.264, MJPEG
Remote viewing with Wisenet Viewer and the Wisenet mobile app

Technical data

Channels	64
Camera resolution	up to 32 MP
Recording bandwidth	520 Mbit/s
Hard disks	16x SATA, max 160TB
RAID	RAID-5/6(Array Size : 8 HDDs x 2 Array)
Monitor output	[Dual Display] HDMI 1: 3840 x 2160 (30Hz) HDMI 2: 1920x1080 (60Hz)
Chassis	3U
Power	100–240 VAC ±10%; 50/60Hz, 2.7A(Dual SMPS)
Weight	15.1 kg
