Pulsar EN54C-5A65 power supply for fire alarm systems, 27.6 V, 5 A, battery 2x65 Ah, EN 54-4

Skip to the end of the images gallery

Skip to the beginning of the images gallery

€278.00 €345

Pre-order

SKU

EN54C-5A65

Product files

Datasheet

Product details

Product parameters
Manufacturer	Pulsar
Length	410
Width	648
Height	180

Toote kirjeldus

Pulsar EN54C is an uninterruptible power supply for fire alarm and smoke and heat control systems. It complies with EN 54-4 and EN 12101-10 and has a certificate of constancy of performance (1438-CPR).

The unit supplies 27.6 V DC on two separately protected outputs (AUX1 and AUX2) and charges and monitors two batteries. The microprocessor measures the battery circuit resistance, compensates the charging voltage for temperature, tests the battery automatically and protects it against deep discharge. Faults are reported to the control panel via the ALARM and EPS relay outputs.

Features

EN 54-4 and EN 12101-10, certificate 1438-CPR
27.6 V DC, two separately protected outputs AUX1/AUX2
Battery circuit resistance measurement and automatic battery test
Temperature-compensated charging, deep discharge protection
ALARM and EPS relay outputs, EXTi external fault input
Short-circuit, overload and overvoltage protection

Technical data

Output voltage	27.6 V DC
Output current (max.)	5 A
Continuous output current	2.4 A
Battery	2x65 Ah
Battery charging current	2.6 A
Standards	EN 54-4, EN 12101-10
Dimensions, mm	410 x 648 x 180
Weight, kg	13.24
Warranty	3 years
EAN	5902135315354
