Sentek BR-1021 magnetic contact | white | recessed | Ø19 mm | for metal doors

Skip to the end of the images gallery

Skip to the beginning of the images gallery

€3.96 €5

In stock 301

SKU

BR-1021WH

Product files

Datasheet

Product details

Product parameters
Manufacturer	Sentek
Length	30
Width	19
Height	19
IP kaitseaste	IP67
Turvakategooria	None
Sobib terasustele	Yes
Paigaldusviis	Flush mount

Toote kirjeldus

Sentek BR-1021 is a recessed magnetic contact designed for steel doors and frames. Contact and magnet are pressed into a 3/4" (19 mm) hole and lock themselves in place. On a steel door the make gap is 19 mm; on other materials it is up to twice as large. The contact has 46 cm leads.

Key features

Suitable for steel doors
Recessed, 19 mm mounting hole
Self-locking
Make gap in steel 19 mm
46 cm leads (22 AWG)

Technical data

Mounting	Recessed
Mounting hole diameter	Ø19 mm
Contact dimensions	29.7 × Ø19 mm (Ø24 mm)
Magnet dimensions	29.7 × Ø19 mm (Ø24 mm)
Make gap	19 mm (on steel)
Release gap	24 mm (on steel)
Contact	NC (closed loop when the door is closed)
Max. switching power	7.5 W
Max. switching voltage	100 V DC/AC
Max. switching current	0.4 A
Contact resistance	≤ 0.15 Ω
Connection	46 cm leads (22 AWG)
Colour	White
