Southwest Microwave INTREPID power supply | 13.6 V DC, 2.5 A | DIN rail, -40 … +70 °C

Skip to the end of the images gallery

Skip to the beginning of the images gallery

€646.88 €802

Pre-order

SKU

PS62

Product files

Datasheet

Product details

Product parameters
Manufacturer	Southwest Microwave

Toote kirjeldus

The PS62 is Southwest Microwave's high-reliability power supply with universal AC input (85–264 V AC) and overload, overvoltage and short-circuit protection. The 30 W version provides 13.6 V DC at up to 2.5 A; full power is available up to +60 °C, from there to +70 °C the output derates linearly by 25 %. It can be installed indoors or outdoors in a weatherproof enclosure; it mounts on a TS35/7.5 or TS35/15 DIN rail and the input and output wiring connects to a terminal strip. Cooling is by convection with 25 mm of free space on all sides. Southwest Microwave offers the PS62 as the 12 V supply for its perimeter devices, such as INTREPID MicroPoint II processors, system controllers and I/O modules.

Key features

Output 13.6 V DC, 2.5 A (30 W), adjustable 12–14 V
Input 85–264 V AC, 47–63 Hz
Overload, overvoltage and short-circuit protection with auto recovery
DIN rail mounting, operating temperature -40 … +70 °C

Technical data

Input	85–264 V AC, 47–63 Hz; 0.56 A (115 V) / 0.33 A (230 V)
Output	13.6 V DC (12.0–14.0 V), 2.5 A, 30 W
Ripple and noise	50 mV peak-to-peak
Protection	overload 105–150 %, overvoltage 120–145 %, short circuit; auto recovery
Operating temperature	-40 … +70 °C (full power to +60 °C), 20–95 % RH
Mounting	DIN rail TS35/7.5 or TS35/15
Compliance	UL (C/US), TÜV, CE, RoHS
MTBF	530,000 h
Dimensions	115 × 40.4 × 90 mm
Weight	0.35 kg
