Tootja | Honeywell |
---|
Ambient temperature | -25 °C ... 55 °C |
Storage temperature | -40 °C ... 70 °C |
Rated Power | 20 W |
Transformer power taps | 20 / 10 / 5 / 2.5 W |
Type of protection | IP 66 |
Material | Aluminum |
Air humidity | < 95 % (non condensing) |
Color | white, similar to RAL 9003 |
Weight | approx. 3.75 kg |
Dimensions | W: 165 mm H: 344 mm D: 150 mm |
Rated impedance | 0,5 / 1 / 2 / 4 kΩ |
Sensitivity EN 54-24, 1 W / 1 m | 91 dB |
Sensitivity EN 54-24, max 1 m | 104 dB |
Transmission range | 300 ... 15000 Hz (-10 dB) |
Dispersion angle | 146° (H) / 87° (V) @ 1 kHz |
Air humidity | < 95 % |
Declaration of Performance | CPR-DoP-2014003 |
