| Tootja | Honeywell |
|---|
| Ambient temperature | -25 °C ... 55 °C |
| Storage temperature | -40 °C ... 70 °C |
| Rated Power | 40 W |
| Transformer power taps | 40 / 20 / 10 / 5 W |
| Type of protection | IP 66 |
| Material | Aluminum |
| Air humidity | < 95 % (non condensing) |
| Color | white, similar to RAL 9003 |
| Weight | approx. 5.75 kg |
| Dimensions | W: 165 mm H: 568 mm D: 150 mm |
| Rated impedance | 0,25 / 0,5 / 1 / 2 kΩ |
| Sensitivity EN 54-24, 1 W / 1 m | 94 dB |
| Sensitivity EN 54-24, max 1 m | 110 dB |
| Transmission range | 300 ... 15000 Hz (-10 dB) |
| Dispersion angle | 147° (H) / 48° (V) @ 1 kHz |
| Declaration of Performance | CPR-DoP-2014003 |
